Smithco SweepStar 48 - Reel Lift Cylinder; Reel Lift Cylinder Drawing

33
Parts
REEL LIFT CYLINDER PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 18-168 Elbow 2
2 HP-18-100 Cotter Pin
1
/8 x 1 1
3 HCP-12-350 Clevis Pin
1
/2 x 3
1
/2 1
4 75-634 Hydraulic Cylinder 1
14-268 Seal Kit 1
TAILGATE CYLINDER PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 HHP-18 Bridge Pin
1
/8 1
2 18-168 Elbow 2
3 75-714 Hydraulic Cylinder 1
14-268 Seal Kit 1
4 HNJ-58-18 Jam Nut
5
/8 - 18 1
5 HNCL -58-11 Center Lock Nut
5
/8 - 11 1
6 18-154 Rod End 1
HG-14-28-180 Grease Fitting
1
/4 - 28 x 180° 1
7 HMB-58-14 Machine Bushing
5
/8 - 14GA 3
8 HB-58-11-200 Bolt
5
/8 - 11 x 2 1
9 HCP-58-175 Clevis Pin
5
/8 x 1
3
/4 1
