Smittybilt XRC8 User Manual

Installation Manual
XRC 8 Specifications
Rated Line Pull: 8000Lbs (3630kgs) single-line
Motor: 5.5hp /12V, Series Wound
Control: Remote Switch, 12’ (3.7m) lead
Gear Train: 3-Stage Planetary
Gear Ratio: 172.8:1
Clutch: Rotating Ring Gear
Brake: Automatic In-The-Drum
Drum Size: (Diameter x Length) 2.5” x 8.82” (63.5mm x 224mm) Wire
Rope: (Diameter x Length) 21/64” x 94’ (8.2mm x 28.5m) Fairlead: 4-
Way Roller
Remote Control: Included
Recommended Battery: 650CCA Minimum for Winching
Battery Leads: 25mm
2
, 72” (1.8m)
Finish: Black
Gross Weight: 94.0lbs (42.5Kgs)
Mounting Bolt Pattern: 10.0” x 4.50”
Line speed and amp draw (first layer)
Line Pull
Lbs
NO LOAD
2000 4000 6000 8000
Kgs 910 1814 2720 3630
Line Speed
Fpm 37.2 18 13.1 10.2 8.2
Mpm 11.4 5.5 4.1 3.2 2.6
Motor Current Amps 75 195 260 335 410
Line pull and cable capacity
Layer of cable 1 2 3 4
Rated line pull per layer
Lbs 8000 6900 5850 5100
Kgs 3630 3130 2650 2310
Cable capacity per layer
Ft 16 42 72 94
Mpm 5 12 21 28

Smittybilt XRC8 Specifications

General

Brand	Smittybilt
Model	XRC8
Category	Winches
Language	English
