Smittybilt XRC8 User Manual

Installation Manual
XRC 10 Specifications
Rated Line Pull: 10000Lbs (4532kgs) single-line
Motor: 5.5hp/12V, Series Wound
Control: Remote Switch, 12’ (3.7m) lead
Gear Train: 3-Stage Planetary
Gear Ratio: 218:1
Clutch: Rotating Ring Gear
Brake: Automatic In-The-Drum
Drum Size: (Diameter x Length) 2.5” x 8.82” (63.5mm x 224mm)
Wire Rope: (Diameter x Length) 23/64” x 94’ (9.2mm x 28.5m)
Fairlead: 4-Way Roller
Remote Control: Included
Recommended Battery: 650CCA Minimum for Winching
Battery Leads: 25mm
2
, 72” (1.8m)
Finish: Black
Weight: 99.0lbs (42.5Kgs)
Mounting Bolt Pattern: 10.0” x 4.50”
Line speed and amp draw (first layer)
Line Pull
Lbs
NO LOAD
2000 4000 6000 8000 10000
Kgs 910 1814 2720 3630 4535
Line Speed
Fpm 29.53 14.44 12.14 10.17 8.86 7.38
Mpm 9 4.4 3.7 3.1 2.7 2.25
Motor Current Amps 70 170 240 310 380 425
Line pull and cable capacity
Layer of cable 1 2 3 4
Rated line pull per layer
Lbs 10000 8633 7716 7089
Kgs 4535 3915 3499 3215
Cable capacity per layer
Ft 16 42 72 94
Mpm 4.88 12.8 21.95 28.5
