Smittybilt XRC8 User Manual

Installation Manual
XRC 8 WINCH PARTS LIST
No.
Parts No. Description Qty No. Part No. Description Qty
01 97281-01 Sun Gear-Input 1 27 97281-27 Inner Gear 1
02 97281-02 Gear Carrier-Input 1 28 97281-28 Clutch Gear 1
03 97281-03 Gear Carrier-Intermediate 1 29 97281-29 Gear Box Tube 1
04 97281-04 Washer-1.2mm thickness 2 30 97281-30 Gasket 1
05 97281-05 Gear Carrier-Output 1 32 97281-32 Gear Box End Cover 1
06 97281-06 Outer Spline 1 33 97281-33 Bolt + Spring Washer 10
07 97281-07 Spline Positioning Bolt 1 34 97281-34 Shaft Sleeve 1
08 97281-08 Drum 1 35 97281-35 Washer 1
09 97281-09 Brake Positioning Bolt 1 36 97281-36 Bearing 1
10 97281-10 Brake System 1 37 97281-37 Clutch Spring 1
11 97281-11 Coupling Joint 1 38 97281-38 Locking Pin 1
12 97281-12 Rotor 1 39 97281-39 Clutch Lever 1
15 97281-15 Motor Long Bolts 2 40 97281-40 Clutch Steel Ball 1
16 97281-16 Motor End Cover 1 41 97281-41 Wire Rope 1
17 97281-17 Carbon Frame & Brush Assy 1 42 97281-42 Wire Rope Fix Bolt 1
18 97281-18 Stator 1 43 97281-43 Screw 4
19 97281-19 Tie Rod Bolt 4 44 97281-44 Spring Washer 4
20 97281-20 Motor Base 1 45 97281-45 Winch Mount Bolt 4
21 97281-21 Nylon Bearing 2 46 97281-46 Clevis Hook 1
22 97281-22 Tie Rod 2 47 97281-47 Roller Fairlead 1
23 97281-23 Bolt 10 48 97281-48 Fairlead Mount Bolt/Nut 2
24 97281-24 Spring Washer 10 49 97281-49 Control Box 1
25 97281-25 Gear Box Base 1 50 97281-50 Remote Control 1
26 97281-26 Gasket 1
