Smittybilt XRC8 User Manual

Installation Manual
XRC 12 Specifications
Rated Line Pull: 12000Lbs (5440kgs) single-line
Motor: 6.6hp/12V, Series Wound
Control: Remote Switch, 12’ (3.7m) lead
Gear Train: 3-Stage Planetary
Gear Ratio: 265:1
Clutch: Rotating Ring Gear
Brake: Automatic In-The-Drum
Drum Size: (Diameter x Length) 2.5” x 8.82” (63.5mm x 224mm)
Wire Rope: (Diameter x Length) 23/64” x 94’ (9.2mm x 28.5m)
Fairlead: 4-Way Roller
Remote Control: Included
Recommended Battery: 650CCA Minimum for Winching
Battery Leads: 25mm
2
, 72” (1.8m)
Finish: Black
Weight: 99.0lbs (45.0Kgs)
Mounting Bolt Pattern: 10.0” x 4.50”
Line speed and amp draw (first layer)
Line Pull
Lbs
NO LOAD
2000 4000 6000 8000 10000 12000
Kgs 907 1814 2722 3630 4532 5440
Line Speed
Fpm 23.5 12.8 10.5 9.4 7.4 6.3 5
Mpm 7.2 3.9 3.2 2.9 2.3 1.9 1.5
Motor Current Amps 65 120 165 215 270 320 370
Line pull and cable capacity
Layer of cable 1 2 3 4
Rated line pull per layer
Lbs 12000 10270 9200 8500
Kgs 5440 4654 4169 3852
Cable capacity per layer
Ft 16 42 72 94
Mpm 5 12 21 28
