Installation Manual
97281/97210/97212
SOLENOID MOUNTING SUPPLEMENT
ST
EP 1: Insert the small metal brackets on the bottom of the solenoid bracket. (Fig A)
STEP 2: Place long mounting brackets on top (hook facing forward) and secure with included bolts. (Fig B,
C)
STEP 3: Place solenoid on top of tie-rods with hooks facing forward in desired location. Secure by
tightening the screws in the rear. (Fig D, E) Installation is now complete. Use the wiring diagram in
instruction manual for further assembly.
(Fig A) (Fig B) (Fig C)
(Fig D) (Fig E)
Tie-Rod (over cable) Mounting Instructions
