32
DAC
Audio Equipment Connected
OTG 1
OTG 2
Instrucons for the two USB A ports: 1. When used as a USB hard disk input, the upper
interface is OTG_1 and the lower interface is OTG_2.
Note: The sum of the two USB output currents does not exceed 2A.
One of them is used as a USB output. When the USB DAC is connected, the “Audio
Device Connecon” is displayed, and at the same me, the digital signal is output from
this USB interface, and the other output of the DP5 are silent. When unplugged, “Audio
Device Disconnect” is displayed, and the original output is restored.
Note: The USB DAC cannot be successfully connected due to USB matching problems.
Audio Equipment Disconnected
Connecng your equipment
To Next Page
