• 15 •
EEBC500B-INT-Z
17. REPLACEMENT PARTS LIST – DIAGRAM
Stock Number Description
EEBC500-1 Replacement wheel w/snap ring
EEBC500-2 Axle
EEBC500-4L Replacement left handle support w/hardware
EEBC500-4R Replacement right handle support w/hardware
EEBC500-4C Center handle bar
EEBC500-5 Front foot w/hardware
EEBC500-6 Positive cable assembly
EEBC500-7 Negative cable assembly
EEBC500-8 Parts storage compartment
EEBC500-9 Clamps posts (2)
