16
Vibrator Configuration
This function will allow user to configure vibrator for On or Off when target is reached for preference
and/or battery power savings.
1. From Settings menu, use UP /DOWN buttons to highlight VIBRATOR CONFIG selection then
press ENTER button.
2. VIBRATOR CONFIG screen is displayed.
3. Use UP /DOWN buttons to toggle ON or OFF selection.
4. Press ENTER button to accept selection and exit to Settings menu.
Battery Type Selection
This function will allow user to configure the battery discharge thresholds for the type of battery used.
1. From Settings menu, use UP /DOWN buttons to highlight BATTERY TYPE selection then press
ENTER button.
2. BATTERY TYPE screen is displayed.
3. Use UP /DOWN buttons to select the type of battery being used.
4. Press ENTER button to accept selection and exit to Settings menu.
EXIT
SHOW INFO
SLEEP TIME
LCD CONTRAST
UP/DOWN buttons
ENTER
button
VIBRATOR
CONFIG
ON
EXIT
ENTER
button
UP/DOWN buttons
VIBRATOR
CONFIG
OFF
EXIT
KEY BEEP
AUTO BACKLIGHT
TOGGLE BACKLGHT
VIBRATOR CONFIG
EXIT
SHOW INFO
SLEEP TIME
LCD CONTRAST
UP/DOWN buttons
ENTER
button
ALKALINE
LITHIUM
NIMH
ENTER
button
UP/DOWN buttons
ALKALINE
LITHIUM
NIMH
AUTO BACKLIGHT
TOGGLE BACKLGHT
VIBRATOR CONFIG
BATTERY TYPE

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Snap-On TECHANGLE ATECH2FR100B and is the answer not in the manual?

Snap-On TECHANGLE ATECH2FR100B Specifications

General IconGeneral
ModelATECH2FR100B
BrandSnap-On
TypeElectronic Torque Wrench
Torque Range5-100 ft-lb
Resolution0.1 ft-lb
Battery2 AA batteries
Drive Size3/8"
Angle Accuracy±1°
Operating ModesTorque, Angle
Unitsft-lb, in-lb, Nm
Torque Accuracy±2% CW, ±3% CCW
