Snap-On TECHANGLE STEEL ATECH4RS600 User Manual

17
x Advanced Configuration
Accessing Advanced Configuration
Advanced configuration is accessed from CONFIGURE menu selection on main menu.
1. From target torque or angle screen, press and hold ENTER   button for 3 seconds.
2. Highlight CONFIGURE menu selection using UP S  /DOWN T buttons.
3. Press ENTER   button to display Configure menu.
Menu Selections:
x EXIT - Exits Configure menu and returns to target torque or angle screen.
x MODE SETUP - Displays wrench mode setup menu.
x CALIBRATION - Displays wrench calibration menu (password protected).
x SET DATE/TIME - Displays clock date and time entry screens.
x SET CAL INTRVAL - Displays calibration interval setup screen (requires clock date and time
setup).
4. To exit Configure menu and return to target torque or angle screen, press ENTER   button while
EXIT menu selection is highlighted.
Note: All user configurable settings are stored in non-volatile memory and are retained while power
is off.
Mode Setup
Mode setup menu allows user to enable/disable Torque THEN angle mode.
1. From Configure menu, press ENTER   button while MODE SETUP selection is highlighted.
2. Mode Setup menu is displayed.
Menu Selections:
x EXIT - Exits Mode setup menu and returns to Configure menu screen.
x THEN DISABLED - Displays THEN Mode enable/disable screen.
3. Use UP S  /DOWN T buttons to highlight menu selections.
4. Press ENTER   button while EXIT menu selection is highlighted to return to Configure menu.
Enable/Disable Torque THEN Angle Mode
This function will allow user to enable or disable Torque THEN Mode.
1. From Mode Setup menu, use UP S  /DOWN T buttons to highlight THEN DISABLED selection
(factory default) then press ENTER   button.
2. TQ THEN ANGLE enable/disable screen is displayed.
3. Use UP S  /DOWN T buttons to select ENABLE or DISABLE selection.
4. Press ENTER   button to accept selection and exit to Mode Setup menu.
EXIT
THEN DISABLED
EXIT
MODE SETUPs
CALIBRATION
SET DATE/TIME
ENTER
button
Configure menu
Mode Setup menu
00
100.0
FT-LB
Target Screen
CLEAR DATA
CYCLE COUNT
SETTINGS
CONFIGUREs
UP/DOWN buttons
EXIT
MODE SETUPs
CALIBRATION
SET DATE/TIME
EXIT
LANGUAGE
SET HEAD LENGTH
M SHOW DATA
ENTER
button
held
ENTER
button
Configure menu
