5
Section 1 - FAMILIARIZATION
FIGURE 1.1
1.1 INTRODUCTION
This manual has been prepared for the operators of
the SNAPPER WALK BEHIND MOWERS. Its
purpose, aside from recommending operating and
routine service requirements, is to promote safety
through the use of accepted operating practices.
Read, Understand and Follow the “IMPORTANT
SAFETY INSTRUCTIONS” on Pages 2 & 3 of this
manual and all safety messages on the mower and
attachments before operating the mower.
1.2 NOMENCLATURE
The nomenclature figure above, Figure 1.1, shows
the essential parts of the SNAPPER WALK
BEHIND MOWERS. It is recommended that all
operators of the mower become thoroughly familiar
with the controls, parts and operation of the mower
before operating. Specific details involving the
engine are found in the separate engine owner’s
manual. Study these manuals before operating and
keep both handy for future reference.
WHEEL DRIVE CONTROL
ENGINE SPEED
ROPE START
BAG SLIDER
FRONT HEIGHT
AIR CLEANER
ENGINE OIL
GRASS BAG
BAG ADAPTER
FULL FILLER
CAP
ENGINE SPEED CONTROL
GROUND SPEED
NOTE: GROUND SPEED
CONTROL HIDDEN IN
FUEL VALVE
