44
Specifications
ENGINE:
20 HP* Briggs & Stratton
Make Briggs & Stratton
Model Vanguard
Horsepower 20 @ 3600 rpm
Displacement 34.8 Cu. in (570 cc)
Electrical System 12 Volt, 16 amp. Alternator, Battery: 340 CCA
Oil Capacity 48 Oz. (1.4 L)
18 HP* Briggs & Stratton
Make Briggs & Stratton
Model Vanguard
Horsepower 18 @ 3600 rpm
Displacement 34.8 Cu. in (570 cc)
Electrical System 12 Volt, 16 amp. Alternator, Battery: 340 CCA
Oil Capacity 48 Oz. (1.4 L)
CHASSIS:
Broadmoor / 300 / 1600 / 2600 Series
Fuel Tank Cap. Capacity: 4.0 Gallons (15 L)
Rear Wheels Tire Size: 22 x 10.00 -10
Inflation Pressure: 6-8 psi (,41-,55 bar)
Front Wheels Tire Size: 15 x 6.00-6
Inflation Press.: 12-15 psi (,8-1 bar)
TRANSMISSIONS:
K57
Type Hydrostatic Tuff Torq K57
Hydraulic Fluid 10w 30 Premium Engine Oil
Capacity 2.1 qt (2,0 L)
Speeds Forward: 5.5 MPH (8,9 km/h)
@ 3400 rpm Reverse: 3.5 MPH (5,6 km/h)
Continuous Torque 159 ft. lbs. (216 Nm)
Output
Drawbar Rating 440 lbs. (200 Kg)
Maximum Weight 674 lbs. (306 Kg)
on Axle
DIMENSIONS:
Broadmoor / 300 / 1600 / 2600 / Series
Overall Length 74” (187 cm)
Overall Width 42” (107 cm)
Height At Top of Seat: 43” (109 cm)
Weight
Broadmoor / 1600 / 2600 Series Tractor
477 lbs. (217 kg)
50” Mower Deck 125 lbs. (57 kg)
44” Mower Deck 112 lbs. (51 kg)
40” Mower Deck 121 lbs. (55 kg)
NOTE: Specifications are correct at time of printing and are subject to change without notice.
* Actual sustained equipment horsepower will likely be lower due to operating limitations and environmental factors.
