Snapper 20SPWM48 User Manual

Not for
Reproduction
14
ASSEMBLY
Fig. 4
(1)
(5)
(2)
(3)
(4)
INSTALLING THE GRASS CATCHER BAG (See Figure 4)
• Lift the rear cover (1).
• Lift the grass catcher by its handle (2) and place under the rear cover so that
the hooks (3) on the grass catcher (4) are seated on the door rod (5).
• Release the rear cover. When installed correctly, the hooks on the grass
catcher will extend through the openings on the rear cover.
NOTE: When using the grass catcher, do not install either the side discharge
deector or the mulching plug.

Snapper 20SPWM48 Specifications

General

Brand	Snapper
Model	20SPWM48
Category	Lawn Mower
Language	English
