Snapper 20SPWM48 User Manual

Not for
Reproduction
35
PARTS LIST
ITEM NO. PART NO. DESCRIPTION QTY
1 84001948 UPPER HANDLE ASSEMBLY
1
2 84001954 HARDWARE, Mounting 1
3 84001929 PIVOT ASSEMBLY, Lower Handle 1
4 84001930 HADWARE KIT, Lower Handle 1
5 84001931 LOWER HANDLE ASSEMBLY 2
6 84001956 HEIGHT ADJUSTMENT ASSEMBLY 1
7 596798 KEY, Safety 1
8 84001935 SPRING, Tension 1
9 84001937 REAR COVER ASSEMBLY 1
10 84001949 REAR WHEEL ASSEMBLY, 10" 2
11 84001938 SIDE DISCHARGE COVER ASSEMBLY 1
12 84001939 MOWER BLADE ASSEMBLY, 20" 1
13 84001940 DEFLECTOR, Side Discharge 1
14 84001942 GRASS CATCHER ASSEMBLY 1
15 84001943 FRONT WHEEL ASSEMBLY, 8" 2
16 84001944 PLUG, Mulching 1
17 84001945 CONTROL PANEL ASSEMBLY 1
18 84001950 SPEED CONTROL ASSEMBLY 1
19
84001946 SAFETY SWITCH ASSEMBLY
1
20
----- MOWER DECK ASSEMBLY
1
21
1697088 BATTERY, 48v 2.0
1
22
1697090
BATTERY, 48v 5.0 1
23
1697092 CHARGER, 48v
1
