700647721"STEEL DECK WALK BEHIND MOWERS
SERIES 20
15
Wheel Brackets & Latches (Self-Propelled)
Part No Descri
p
tionItem Qty
1 7500038 1 ASSEMBLY, Front Left Wheel Arm (.512” Square Hole)
1 7051885 1 ASSEMBLY, Front Left Wheel Arm (.453” Square Hole) (used on 7800427 only)
2 7051886 1 ASSEMBLY, Front Right Wheel Arm
3 7054247 1 ASSEMBLY, Wheel Arm Left Rear Long SP21S
4 7054246 1 ASSEMBLY, Wheel Arm, Right Rear (S.P.)
5 7011393 1 WHEEL ARM, L.H. Front (.512” Square Hole)
5 7031016 1 WHEEL ARM, L.H. Front (.453” Square Hole) (used on 7800427 only)
6 7015761 2 BOLT, 5/16-18 x 3/4” Hex Washer Face Shoulder
7 7011791 4 RETAINER, 5/16” Bolt
8 7012325 2 LATCH, Height
9 7100633 4 GRIP, Height Latch
10 7031017 1 WHEEL ARM, R.H. Front (Round Hole)
11 7032723 1 ARM, Wheel, Left Rear
12 7011078 2 BOLT, 5/16-18 x 1” Hex Washer Face Shoulder
13 7035717 2 LATCH, Height Adjusting (long)
14 7032722 1 ARM, Wheel, Right Rear
15 7100752 1 AXLE, Front, Easy Line (3/8-16 Threads)
15 7021119 1 AXLE, Front, (7/16-20 Threads) (used on 7800427 only)
16 7091601 4 NUT, 5/16-18 Hex Flange Lock, GR 5 (was 7090585 or 7091070)
17 7900018 2 SCREW, Round Washer Head Torx, Hi-Lo
18 7100196 1 COVER, Front 21” walk
19 7012312 2 BEARING, 9/16” I.D.
20 7091012 6 SCREW, #10-32 x 3/8” Hex Washer Self-Tap
