Snapper SERIES 20 - Grass Bag Components

Not for
Reproduction
Footnotes:
Manual No.
700647721"STEEL DECK WALK BEHIND MOWERS
SERIES 20
27
Grass Bag Components
Part No Descri
p
tionItem Qty
1 7500153 1 BAG ASSEMBLY, (Door) (includes items 2, 3 & 4)
2 7100433 1 GRASS BAG, (Door) No Graphics
3 7042489 1 CONNECTOR, Grass Bag (weldment)
4 7051906 1 ASSEMBLY, Bag Wire (12” Wide)
5 7090189 2 WASHER, 5/16” Internal/External Tooth Lock
6 7091527 1 SCREW, 5/16-18 x 1-1/4” Hex Head Cap (was 7091984)
7 7047082 1 BRACKET, Rope Guide
8 7091601 2 NUT, 5/16-18 Hex Flange Lock, GR 5 (was 7091070)
9 7072107 3 WASHER, 15/32” Flat
10 7013860 3 RIVET, 3/16 x .344
11 7012306 1 BUSHING, Flange, .381 x .625 x .62
12 7091508 3 BOLT, 5/16-18 x 3/4” Short Neck Carriage GR 5
13 7011791 3 RETAINER, 5/16” Bolt
14 7024340 1 SPACER, .316 I.D. x .375 O.D. x .310 thick
15 7090951 1 NUT, 5/16-18 Hex Large Flange Center Lock
16 7047081 1 ADAPTER, Grass Bag
17 7101022 2 KNOB, Fluted, 5/16-18 x 1/2”
18 7024228 1 PULLEY, Nylon
19 7058037 1 ASSY, Grass Bag Adapter (includes items 6, 7, 8, 9, 10, 11, 16 & 18)
20 7016814 1 PLUG, Chute Adapter
