Snapper SERIES 20 - Accessory Snapperizer

Not for
Reproduction
Footnotes:
Manual No.
700647721"STEEL DECK WALK BEHIND MOWERS
SERIES 20
31
Accessory Snapperize
r
Part No Descri
p
tionItem Qty
-- 7063041 KIT, Snapperizer (Incl. items 1 thru 5) (for “FR” & “M” type outlip decks)
1 7051243 1 SCREEN, Fastener Assembly
2 7072002 1 RING, Bottom (22.60” Inside Diameter)
3 7091297 3 NUT, 5/16-24 Hex, GR 5
4 7090187 3 WASHER, 5/16” Split Lock
5 7012587 3 SPRING
