Snapper SERIES 20 - Electric Start Components

Not for
Reproduction
Footnotes:
Manual No.
700647721"STEEL DECK WALK BEHIND MOWERS
SERIES 20
33
Electric Start Components
Part No Descri
p
tionItem Qty
1 7067012 1 KIT, BATTERY, 12 Volt, 35 CCA (includes items #1 and 2)
2 7015488 1 HARNESS, Battery
3 7043977 2 SCREW, #10-24 x 1/2” Pan Head Machine
4 7090932 2 NUT, #10-24 Square
5 7011791 1 RETAINER, 5/16” Bolt
6 7011138 1 KEY, (Set of Two) (7041710, Switch Assembly, includes items 6 through 11.)
7 7023506 1 BEZEL, (Seal & Face Nut)
8 7029080 1 COVER, Switch
9 7012685 1 NUT, 5/8-32 Hex Lock
10 7028765 1 SWITCH, Ignition (spring loaded ON/OFF 2 prong)
11 7016132 1 SPACER
12 7078025 1 WIRING HARNESS, B&S WBM
13 7032906 1 BRACKET, Battery
14 7036132 1 COVER, Battery
15 7090731 2 BOLT, 5/16-18 x 1/2” Short Neck Carriage GR 5
16 7090585 3 NUT, 5/16-18 Hex Flange Lock, GR 5 YZ (or 7091601)
17 7012652 1 CLIP, Wiring
18 206838YP 1 CHARGER, Battery (120 Volt; 60 Hertz) (order Kit # 206838: Kit, Battery Charger)
19 7090799 1 BOLT, 5/16-18 x 5/8” Short Neck Carriage GR 5 (was 7091026)
