Manual No.
700647721"STEEL DECK WALK BEHIND MOWERS
SERIES 20
19
Drive System Self-Propelle
Part No Descri
tionItem Qty
44 7090585 4 NUT, 5/16-18 Hex Flange Lock, GR 5 ZP (or 7091601)
45 7029025 1 SPRING, Wheel Drive
46 7090731 1 BOLT, 5/16-18 x 1/2”, Short Neck Carriage, GR 5
47 7090799 1 BOLT, 5/16-18 x 5/8” Short Neck Carriage GR 5 (was 7091026)
48 7091302 1 NUT, 3/8-16 Hex
49 7013847 1 RETAINER, 3/8” Bolt
50 7052987A 1 ASSEMBLY, Deck Bracket (Incl. items 52, 53 & 59)
51 7031919 1 BRACKET, Deck - Replaced (use Items 59 & 60 or Items 51, 52 & 53)
52 7012306 2, 4 BUSHING, Flange, .381 x .625 x .62
53 7021758 1 SPACER, .500 x .65 x 1.75
54 7061275 KIT, Drive Disc Assembly (Includes Items 42, 43 & 48)
55 7051913 1 ASSEMBLY, Clutch Idler (Includes Items 24, 25, 26 & 56)
56 7500154 1 ASSEMBLY, Idler Arm (Includes Items 52, 57 & 58)
57 7032832 1 ARM, Clutch Idler
58 7100447 1 SPACER, Idler Arm
59 7033774 1 BRACKET, Deck, P21S
60 7012117 4 BUSHING, 3/8” I.D. Nylon
61 7074139 1 ASSEMBLY, Driven Disc (includes items 20, 21, & 30 thru 35)
62 7600109 1 ASS'Y, Driven Disc, Short, Commercial (Incl. same items as Kit 7061276 plus items 20, 21, 30
& 32)
-- 7501000 ASS'Y, Driven Disc- Commercial (can be used instead of items 20, 21, 30, 31, 32, 33, 34, 35 &
71)
63 7090913 7 SCREW, #10-24 x 1/2” Hex Washer Self-Tap (Torx)
64 7031013 1 SIDE PLATE, Drive Tire
65 7023364 1 DRIVEN RING (was 7010927)
66 7061276 1 KIT, Hub & Bushing (Incl. Items 20, 21, 30, 31, 32, 34, 35, 63, 64, 65, 67, 68 & 69) (was
7053217)
67 7011108 1 BUSHING, Drive, Hex
68 7010121 1 WASHER, Shim, .75 x 1.0 x .021
69 7090981 4 SCREW, #10-32 x 1/4” Hex Washer Self-Tap
70 7059462 1 ASSEMBLY, Deck Bracket (Incl. items 59 & 60)
71 7501961 1 ASSEMBLY, Thrust Plate & Bearing (includes items 31 & 35)
72 7051921 1 ASSEMBLY, Clutch Idler (Includes Items 24, 25, 26, 52 & 57)
