Manual No.
700647721"STEEL DECK WALK BEHIND MOWERS
SERIES 20
5
Handles and Controls
NOTE: * Part number and revision is stamped on cable.
Part No Descri
p
tionItem Qty
1 7074411 1 HANDLE, Upper
2 7023810 1 FOAM GRIP, 18.75” long
3 7074418 1 BAIL, OPC Control
4 7034872 1 CLIP, Zone Control
5 7074156 1 HANDLE, Middle
6 7033985 1 HANDLE, Lower LH (Adjustable)
7 7033986 1 HANDLE, Lower RH (Adjustable)
8 7074140 1 CONTROL PANEL (w/o Electrical Switch Hole) (Used on Manual Start Models)
8 7074469 1 CONTROL PANEL (w/Electrical Switch Hole) (Used on Electric Start models)
8 7073826 1 CONTROL PANEL (w/o wheel drive slot) (used on 7800428 & 7800437)
9 7091200 4 SCREW, 1/4-20 x 1/2” Pan Head Self-Tap (Torx)
10 7074473 1 HANDLE, Clutch
11 7028407 1 GRIP, International Symbol
12 7023792 1 PIN, 1/4 x 1-1/2”
13 7014343 2 BUSHING, .27 x .35 x .4 Flange
14 7091020 1 PUSH-NUT, 1/4”
15 7079577 1 SCREW, 1/4-20 x 1-1/2” Hex Head Cap GR 5
16 7034608 1 * CABLE, Zone Control (52-63/64” Long) (used on 7800425, 7800428, 7800429, 7800437,
7800596, 7800597 & 7800602)
16 7102593 1 * CABLE, Zone Control (52-21/32” Long) (used on 7800424, 7800552, 7800553, 7800554,
7800555, 7800754, 7800758, 7800759 & 7800771)
16 7078078 1 * CABLE, Zone Control (50-31/64” Long) (used on 7800427 & 7800432 models only)
17 7090053 5 WASHER, 1/4” Internal Tooth Lock (was 7091023)
18 7091576 3 NUT, 1/4-20 Hex (was 7091100)
19 7023813 1 CLIP, Wiring Harness
20 7074460 1 THROTTLE CONTROL, (48.5”) (used on all models except for those shown below)
20 7100975 1 THROTTLE CONTROL, RP, D.O.V. Engine (50.0”) (used on 7800424 model)
20 7102594 1 THROTTLE CONTROL, (62.0”) (used on 7800552, 7800554, 7800555, 7800553, 7800754,
7800758, 7800759 & 7800771)
21 7075308 1 THROTTLE KNOB, (Red)
22 7090505 2 SCREW, 1/4-20 x 2” Hex Head Cap, GR 5
23 7028488 1 GUIDE, Rope (1/4-20 thread)
24 7076978 1 NUT, 1/4-28 Hex GR 5 or B
25 7034604 1 CABLE, Clutch Control (41-1/4” Long)
26 7012121 1 COVER, Vinyl
27 7012122 1 SPRING, Clutch - 21S
28 7026219 1 CLAMP, 7/8” Double Cable
29 7091189 4 SCREW, 5/16-18 x 1-7/8” Curved Head GR 2 (was 7091740)
30 7012080 2 CABLE-TIE, 7”
31 7090391 4 WASHER, 5/16” Internal Tooth Lock
32 7023153 1 CLAMP, Casing
33 7074003 1 BRACKET, Shift
34 7091305 1 SCREW, 3/8-16 x 2” Hex Head Cap, GR 5
35 7031961 2 WASHER, 7/16” Flat
36 7028465 2 WASHER, Nylon
37 7074113 1 LEVER, Shift
