Manual No.
700647721"STEEL DECK WALK BEHIND MOWERS
SERIES 20
9
Engine, Cutting Deck & Blade
NOTE: * Purchase engine parts from engine manufacturer dealer.
Part No Descri
tionItem Qty
1 7500081 1 WELDMENT, Deck, 21” Non-Adjust Air (red, w/o decals) (used on “R” (recycling) models)
1 7400029 1 WELDMENT, Deck, 21” Push, HV, Core Model (red, w/o decals) (used on 7800428 & 7800437
(push) models)
1 7500549 1 WELDMENT, Deck, Part Sales, Hi-Vac, ES (red, w/decals) (used on self-propelled (non-
recycling) models)
2 7091508 1 BOLT, 5/16-18 x 3/4” Short Neck Carriage GR 5 (was 7090001)
3 7091601 2 NUT, 5/16-18 Hex Flange Lock, GR 5 (was 7091070)
4 7046780 2 PLUG, Hole, Polyethylene
5 7090324 3 SCREW, 3/8-16 x 1” Self-Tapping (engine mount bolts)
6 7074568 1 COVER, Belt
7 7091214 1 KEY, Woodruff #HP-506 Hi-Pro
8 7015780 1 PULLEY, Engine (25mm I. D. x 2-1/8” O.D.)
9 7090201 1 SET SCREW, 5/16-18 x 5/16” Hex Socket (or 7092086 (SET SCREW, 5/16-18 x 1/2” Hex
Recess))
10 7101414 1 HUB, Blade, 21” WBM, RD, 2 Position
11 7026691 1 BLADE, 21” Standard Lift
12 7012063 2 WASHER, Cone 3/8”
13 7090167 1 SCREW, 3/8-24 x 2” Hex Head Cap, GR 5
14 7015626 1 HUB, Blade Drive, 25 mm I.D.
15 7026407 1 BLADE, 21” Ninja (Quad Edge) (Used on Recycling Models)
16 7029149 1 COVER, 21” Deck
17 7090189 2 WASHER, 5/16” Internal/External Lock
18 7101022 2 KNOB, Fluted, 5/16-18 x 1/2”
19 7011791 1 RETAINER, 5/16” Bolt
20 7024340 1 SPACER,.316 ID x .375 OD x .310 thick
21 7090951 1 NUT, 5/16-18 Hex Large Flange Center Lock
22 7091169 1 BOLT, 5/16-18 x 1-1/8” Round Head Short Square Neck, GR 5, ZP
23 7044770 3 SPACER, Blade Hub (Used on 7800427 & 7800553)
24 100602-0155-B8 1 * ENGINE, B&S DOV 700 Series (used on 7800424 (RP217020BDV))
24 121Q72-0110-F1 1 * ENGINE, B&S 875 Professional Series, California Compliant (used on 7800692 (NP2187520))
24 126L02-4113-F1 1 * ENGINE, B&S 675 Series (used on 7800437 & 7800438
24 126T02-0267-B1 1 * ENGINE, B&S 675 Series (used on 7800428 & 7800429)
24 128L02-0114-F1 1 * ENGINE, B&S 700 Series, California Compliant (used on 7800600 & 7800601)
24 12S502-0112-B1 1 * ENGINE, B&S 875 Series, Intek (used on 7800425, 7800430 & 7800492)
24 12S507-0115-B1 1 * ENGINE, B&S 875 Series, Intek (used on 7800432 & 7800427)
24 12S602-0110-F1 1 * ENGINE. B&S 875 Series, Snapper, XIC, F1 (used on 78000439 (NP2187520BV))
24 12S902-0126-B1 1 * ENGINE, B&S 875 Series, W14 (used on 7800552 & 7800554)
24 12S907-0127-B1 1 * ENGINE, B&S 875 Series, W14, ES (used on 7800553 & 7800555)
24 12S972-0152-B1 1 * ENGINE, B&S, 875 Series, W14 w/oil fltr, 49 ST (used on 7800754 & 7800758)
24 12S977-0153-B1 1 * ENGINE, B&S, 875 Series, W14 w/oil fltr (used on 7800759)
24 121S72-0111-F1 1 * ENGINE, 875 Series, Snapper California Compliant (used on 7800771)
