Snapper ST48 User Manual

ATTACH THE GUARD
(
See
Figures 3.1 - 3.3
)
NOTE: Install the guard before the attachment is connected to the lower shaft.
1. Invert the string trimmer to access the trimmer head.
2. Remove supplied screws (1) from the guard with a philips screwdriver (not
included).
1
3. Slide the guard (1) into the slots on the trimmer head.
4. Align the screw holes on the guard (2) with the screw holes on the trimmer
head (3).
1
3
2
5. Insert the screws into the trimmer head, fastening the guard in place
using a philips head screwdriver (not included).
ASSEMBLY
12
Fig. 3.1
Fig. 3.2
Fig. 3.3
