19
OPERATION
ADVANCING LINE
(See
Figure 10.
)
While the string trimmer is operating, the cutting line gets worn down and
becomes shorter. This trimmer is equipped with bump feed line advancement,
which advances additional line once the head is bumped on the ground while
rotating. The cutting blade will cut the line to keep an accurate cutting swath.
SPOOL REPLACEMENT
(See
Figures 11.1 - 11.7
)
1. Remove the battery pack from the tool.
2. Press the tabs simultaneously on the side of the trimmer head and
remove cover and spool.
3. Remove any remaining line.
4. Clean dirt and debris from all parts. Replace spool if it is worn or
damaged.
5. Replace with a pre-wound spool, or replace line using 15 feet (4.6
meters) of 0.080 inch (2.0 mm) diameter line.
WARNING
Never use wire, rope, string, etc., which can break off and become a dangerous
projectile.
Cover
Spool
Tab
Fig. 11.1
Bump head
Fig. 10
