ASSEMBLY
CONNECTING THE SHAFTS (See Figures 2-3)
• Align the pin on the handle shaft and the hole on the lower shaft. (Fig. 2)
• Once the two shafts are secured, turn the lock knob clockwise until it is fully tightened. (Fig. 3)
Fig. 3
Fig. 2
Lower shaft
Handle shaft
Pin
Hole
