29
MAINTENANCE
• Remove the battery from the chain saw.
• Remove the supplied wrench from the rear
handle.
• Remove the two chain cover lock nuts from the
chain cover by rotating them counterclockwise
with the wrench.
• Remove the chain cover from the mounting
surface.
• The bar and chain can now be removed by
lifting it away from the main body of the saw and
releasing the chain from the sprocket.
• Remove the old chain from the bar.
• Lay out the new saw chain in a loop and
straighten any kinks. The cutters should face
in the direction of chain rotation. If they face
backwards, turn the loop over.
• Place the chain drive links into the bar
groove.
Chain rotation
Chain drive links
Cutters
Chain cover
Lock nuts
Wrench
Chain
Bar
Sprocket
