Snapper XD Series User Manual

12
OPERATION
USING THE ROTATING REAR HANDLE (See Figure 4.)
1. Place the hedge trimmer on a at and even surface.
2. Make sure that you released the trigger.
3. Pull the rotation lever and begin turning the rear handle. Release the rotation lever and turn
the handle 90 degrees to either side until it clicks into place and the lever locks in.
4. To turn the handle back to center, pull the rotation lever again, turn the handle slightly, release
the rotation lever and continue turning the handle until it locks into place.
ANTI-JAMMING FUNCTION (See Figure 5.)
If a branch is lodged in the blade, press the anti-jamming button on the control panel, the blade
will reverse twice, and the branch should be released.
FIG.4
FIG.5
Anti-jamming button
Not for Reproduction
