Snapper XD Series User Manual

14
BATTERY & CHARGER MAINTENANCE
CHARGER MOUNTING
1. This charger can be installed hanging on a wall using two #8 screws (not included).
2. Locate the placement for the charger to be wall mounted.
3. If fastening to wood studs use 2 wood screws (not included).
4. Drill two holes on center 4.5 in. apart ensuring that they are vertically aligned.
5. If fastening to drywall use wall anchors (not included) and screws to secure the charger to the
wall.
6. This power unit is intended to be correctly orientated in a vertical or oor mount position.
NOTE: If the battery and the charger won’t be used for a long time, remove the battery from the
charger and pull out the AC power plug.
Not for Reproduction

Snapper XD Series Specifications

General

Chain Brake	Yes
Engine Displacement	42 cc
Power Source	Gasoline
Bar Length	18 inches
Chain Pitch	0.325 in
Chain Gauge	0.050 inches
