PARTS LIST

ITEM NO. PART NO. DESCRIPTION QTY

14 770220 KIT, MOTOR 1

136 ----- PINION 1

137 ----- MOTOR 1

138 ----- SLEEVE, GEAR SHAFT 1

15A 770221 KIT, LEFT HOUSING, NA 1

139 ----- SCREW 4

140 ----- GASKET, SPRING 4

141 ----- CLAMP 1

142 ----- HOUSING, LEFT 1

143 ----- NUT, SQUARE THE M5 2

144 ----- NUT, BEFORE THE HANDLE 1

145 ----- SCREW 7

16A 1760266 BATTERY, 2AH, NA (OPTION) 1

17A 1760263 CHARGER, RAPID, NA (OPTION) 1

18A 1760265 BATTERY, 4AH, NA (OPTION) 1
