Figure 9. Trailer Weight Recommendations
A
Attaching a Trailer
The maximum weight of a towed trailer should be less
than 200 lbs (91 kg). Secure the trailer with an appropri-
ately sized clevis pin (A, Figure 9) and clip ().
Excessive towed loads can cause loss of traction and
loss of control on slopes. Reduce towed weight when
operating on slopes. The surface being driven on greatly
impacts traction and stability. Wet or slippery surfaces
can greatly reduce traction and the ability to stop or turn.
Carefully evaluate the surface conditions before oper-
ating the unit and trailer, and never operate on slopes
greater than 10°. See Protection Against Tipovers and
Towing in the Operator Safety section of this manual.
3’6”
(1m)
20’ (6m)
19
en
