3
XA 90
ps
XA 75
ps
XA 55
cr
Frequency Response (
±
3dB) 32–22,000Hz 34–22,000Hz 55–22,000Hz
Nominal Impedance 4 ohms 8 ohms 4 ohms
Recommended Amplifier Power 100–300 watts 75–300 watts 50–300 watts
Sensitivity [2.83v at 1m (1 watt)] 90dB 88dB 88dB
Driver Complement
(all video-shielded)
Front Tweeter 1" (25mm) black anodized 1" (25mm) black anodized 1" (25mm) black anodized
aluminum, separate PVC aluminum, separate PVC aluminum, separate PVC
surround surround surround
Midranges 2 x 2.5" (60mm) 2 x 2.5" (60mm) 2 x 2.5" (60mm)
Woofers 2 x 6.5" (160mm) 1 x 6.5" (160mm) 2 x 6.5" (160mm)
Distortion-reducing Distortion-reducing Distortion-reducing
magnetic circuit magnetic circuit magnetic circuit
Subwoofer(s) 2 x 10" (250mm) 1 x 10" (250mm) none
Dual spider, heatsink Dual spider, heatsink
Rear Tweeter 1" (25mm) 1" (25mm) none
Subwoofer Amplifier 300 watts 200 watts none
Controls Parametric bass EQ, Bass level, LFE level, treble Treble level, boundary
bass level, LFE level, level, boundary compensation, compensation
treble level, boundary rear tweeter
compensation, rear tweeter
Cabinet Construction Heavily braced, veneered Heavily braced, veneered Heavily braced, veneered
MDF
3
⁄
4
" minimum MDF
3
⁄
4
" minimum MDF
3
⁄
4
" minimum
Baffle Construction Rubber isolated: constrained Rubber isolated: constrained Rubber isolated: constrained
layer damping, low diffraction layer damping, low diffraction layer damping, low diffraction
radius radius radius
Grille Frameless perforated metal Frameless perforated metal Frameless perforated metal
over 51% open area over 51% open area over 51% open area
Maximum Dimensions (HxWxD) 54.5 x 11 x 19.5" 46 x 11 x 19.5" 9 x 22.5 x 11"
(138 x 28 x 50cm) (117 x 28 x 50cm) (23 x 57 x 28cm)
Weight, Net 125lbs (57kg) 100lbs (45kg) 39lbs (18kg)
Shipping Weight 198lbs (90kg) 166lbs (76kg) 44lbs (20kg)
Finishes Black Oak, Cherry, others Black Oak, Cherry, others Black Oak, Cherry, others
to special order to special order to special order
SPECIFICATIONS
