Snorkel TM12E - Page 53

アイテム 部品番号 名前 数量 UOM
27 10000152 BRKT,BATTERYBRACE 2 EA
28 10001240 ASSYSTEPPYLON 1 EA
29 10000038 PLATE,TOEKICK 1 EA
30 10001633 ASSY,LWRCTRLPNL,W/OL 1 EA
31 10001203 TM12HUBASSY 2 EA
32 10000333 STEERINGLINK,CAST 2 EA
33 2580430 THRUSTBRG,80mmID
100mmOD3mmTHK
2 EA
34 10000073 CYLINDER,STEER 1 EA
35 10000337 PIN,STEERCYLTEE 1 EA
36 10000157 PIN,STEERCYLCENTER 1 EA
37 10000159 PLT,STEERPINKEEPER 1 EA
38 10000330 STEERINGTEE,CAST 1 EA
39 10001105 WELD,STEERPIN 4 EA
40 1610015-000 GUARDPROTECTIVEHEAT
SHRINK(NOTSHOWN)
1 EA
41 3087803 EZCalPanel-Trionics 1 EA
42 13161-000 SWITCH 1 EA
43 13162-000 SWITCHLOCK 1 EA
44 3028844 IFS241(IFMPROXY) 3 EA
45 13201-000 RELAYSOLENOIDNOSPST
24VDC
1 EA
46 3049978 ALARMBEEPING 1 EA
47 10001095 HORN 1 EA
48 467966 STATICSTRAPRUBBERGRD
30in
1 EA
49 1610016-000 CONTROLLER,MODULE,
SEM300
1 EA
50 13006-016 FUSEBLOCKBOLT-INLITTLE 1 EA
51 010154-000 COVERBATTERY 8 EA
52 13006-010 MEGAFUSE,250AMP 1 EA
53 10001363 KIT,HOSETM100 1 EA
TM12E PARTS MANUAL
CHASSIS TM SEM300 TM SEM300-11-XXXXXX AND AFTER
CHASSIS TM SEM300 TM SEM300-11-XXXXXX AND AFTER
Mon Feb 15 04:09:08 UTC 2021 2-5
