Snugger SF2300 - Parts List of SF2300 Air Heater

SF2300 Technical Manual
Page 23
Parts List of SF2300 Air Heater
Item
Parts No.
Description
Qty
1
230101
Heat exchanger housing
1
2
230205
Air outlet
1
3
230201
Clamp spring
1
4
230207
Rubber buffer
1
5
230403
Sealant foam
1
6
230209
Plug
1
7
230204
Air inlet hood
1
8
230208
Safety screen
1
9
235025
Pan head screw M5 x 25, spring washer
4
10
230120
Combustion fan
1
11
230206
Gasket, heat exchanger
1
12
230500
Control Unit
1
13
234010
Cross recessed pan head screw M4 x 10, spring washer
2
14
235010
Pan head screw M5 x 10, spring washer
3
15
230110
Burner Assembly
1
16
230105
Grommet
1
17
230106
Seal gasket
1
18
230202
Top cover 1
1
19
230108
Clamp spring
1
20
230310
Temperature Sensor
1
21
2303A/B
Glow Pin
1
22
23004
Hexagon Socket
1
23
230115
Burner filter screen 1
1
