Snugger SF2300 - Mounting Heater Without Mounting Plate

SF2300 Technical Manual
Page 8
Mounting heater on the floor or wall without mounting plate
The heater can only be mounted without using the mounting plate when the floor or wall it is to be
mounted to is smooth and even. If the floor or wall is not smooth or even it is not possible to get a
proper seal with the rubber gasket on the bottom of the heater.
1. Rubber Gasket
2. Smooth Wall
3. Lock Washer X 4
4. Nut X 4
