CHAPTER 5: SETUP FOR WINDOWS PC 47
OPTION 1: USING THE CHS IN HID MODE
To prepare the CHS for pairing:
You only need to pair the CHS with your computer the first time you try to connect.
1. Power on the CHS. Press and hold the small power button until the LED turns blue and
the CHS beeps twice (low-high).
The LED blinks blue once per second to show that the Bluetooth radio is on but not
connected.
2. Scan this barcode to configure the CHS for HID mode for peripherals. Afterwards, the
CHS will beep 3 times.
By default, the CHS is in HID Keyboard mode. If the CHS was changed to SPP mode,
first use the Command Barcodes
to change the CHS to HID mode before scanning the
barcode above.
In the next step, you will need to know the type of Bluetooth stack on your
computer. Click Start. Right-click on My Computer and click Properties | Hardware
tab | Device Manager and identify the manufacturer of your Bluetooth device.
