50
Set Lengths for Interleaved 2 of 5
Parameter # L1 = 0x16, L2 = 0x17
The length of a code refers to the number of characters (i.e., human readable characters),
including check digit(s) the code contains. Lengths for I 2 of 5 may be set for any length,
one or two discrete lengths, or lengths within a specific range. To set lengths via serial
commands, see Setting Code Lengths Via Serial Commands on page B-7.
Note: When setting lengths, single digit numbers must always be
preceded by a leading zero.
One Discrete Length - Select this option to decode only those codes containing a selected
length. For example, select I 2 of 5 One Discrete Length, then scan 1, 4, to decode only
I 2 of 5 symbols containing 14 characters. Numeric bar codes begin on page 82. To
change the selection or cancel an incorrect entry, scan the Cancel bar code on page 84.
I 2 of 5 - One Discrete Length
Two Discrete Lengths - Select this option to decode only those codes containing two
selected lengths. For example, select I 2 of 5 Two Discrete Lengths, then scan 0, 6, 1, 4,
to decode only I 2 of 5 symbols containing 6 or 14 characters. Numeric bar codes begin
on page 82. To change the selection or cancel an incorrect entry, scan the Cancel bar
code on page 84.
I 2 of 5 - Two Discrete Lengths
