32
slipper carrying box
Put the slipper tool into the slipper carrying box, shown as below.
(1) (2) (3) (4) (4) (3) (2) (1)
Put the slipper tool (1) into the slipper carrying box. Then tighten the screw (2) to fasten the spring
carry bar. Loosen the M20 cap headed screw (3) and use the jacking screw (4) to move the slipper
carrying box until the correct clearance is obtained.
