ATySController C55/65 - 549866C - SOCOMEC
FUNCTION
TRIGRAM
(ECS)
TIMER DESCRIPTION
SELECTABLE
RANGE
BY
DEFAULT
Tripping action CH1/CH2
CHARGING TIME
(s)
Time needed to charge the breaker 1/2 spring mechanism,
during this time new orders to transfer will be placed on hold,
these timers will be bypassed if the breaker charged inputs are
activated.
0-15 0
Load adding PreODx
PRE TRANSFER
TIMER (s)
Before transfering this all On delay outputs will be activated
when this timer initiates. Transfer will only be allowed at the end
of this timer
0-99 0
Load adding OD1-OD7
ON DELAY TIMER
1-7 (s)
Time after transfer for which the ON DELAY output will be
active (up to 7 timers).
0-3600
Timer
number
x20s
Cycler 1CY/2CY
S1/S2 CYCLE
DURATION (h)
Duration of a cycle for a source, at the end of the cycle the
controller will initate a transfer based on transfer settings.
0-9999 1
Annex 16 - 3. Input list
These options can be congured in the Parameters / I/O / Inputs menu:
TRIGRAM INPUT NAME DESCRIPTION C65 C55
AC1 SWITCH IN POS.1 / BRK 1 CLOSED Read position 1 from the RTSE x x
AC2 SWITCH IN POS.2 / BRK2 CLOSED Read position 2 from the RTSE x x
AC0 SWITCH IN POS.0 Read position 0 from the RTSE x x
AC0A SWITCH A S1 IN POS.0 / BRK1 OPEN Read position 0 from the SWITCH on S1 x x
AC0B SWITCH B S2 IN POS.0 / BRK2 OPEN Read position 0 from the SWITCH on S2 x x
MAN RTSE IN MAN
RTSE In Manual Mode:
This input is connected to the switch to inform the controller that the switch is
in maintenance mode (door is open for servicing). The controller commands
will be inhibited but navigation through the menu and dashboards on the
display are allowed. This situation will remain until the input is cleared. Screen
will show the following message when the input is activated "INHIBIT MODE
RTSE IN MANUAL"
x x
LCK PADLOCK
Product padlocked. Screen will show "INHIBIT MODE PRODUCT PADLOC-
KED" while the input is active. Controllers goes to Inhibit mode until input is
cleared. The controller commands will be inhibited but navigation through the
menu and dashboards on the display are allowed.
x x
IEE INH. GENSET SCH.
Inhibit Engine Exerciser:
This input will inhibit the Engine Exerciser automatic functioning. All custo-
mized exercising programs will be bypassed and not take place whilst this
input is active.
x -
POP RTSE AVAILABLE Information coming from the RTSE to inform that the RTSE is operational. x x
PS1 GO TO POS.1
External order to go to pos 1
Position command only available if mode is in position CTRL. The last com-
mand received has priority.
x x
PS2 GO TO POS.2
External order to go to pos 2
Position command only available if mode is in position CTRL. The last com-
mand received has priority.
x x
