ATYS D10 / D20 - 542359B - SOCOMEC
(1) Only accessible if the Setup menu
variable "APP" is at "M-G", see Setup Menu.
(2) Only accessible if the Setup menu
variable "APP" is at "M-M", see Setup Menu.
(3) Only accessible if one of the inputs is
EON, see I/O Menu.
(4) Only accessible if one of the inputs is
EOF, see I/O Menu.
(5) Only on the COMM version, see
description in the option section.
(6) Only accessible if one of the outputs is
LSC, see I/O Menu.
(7) Default values: 230 V for 127/230
version Default values: 400 V for 230/400 version
(8) Only accessible when the "RETURN
O" variable in the Setup menu is set to "YES", see SETUP menu..
(9) Only accessible if the associated input
is configured.
* UNL = Unlimited
5.2.2.2. Architecture valid for ATyS M 6e (master)
