socomec COUNTIS E45 Operating Instructions

COMPLIANCE
European EMC Directive No. 2004/108/EC (15/12/2004)
LV Directive No. 2006/95/EC Dated 12 December 2006
IEC 62053-21 / IEC 62052-11
SYSTEM CONNECTION
Supply types / number of wires Single phase 2 wires 230V / Two phase 2 wires 400V
Three phase 3 wires 3x230V / 3x400V and Three phase 4 wires
3x230/400V
Management Detection of cabling error
Frequency 50 and 60 Hz (± 5 Hz)
SUPPLY Autosupplied
CONSUMPTION
Supply <10VA or 2W
Current circuit <1.0VA
CURRENT (TRMS)
Starting current (Ist) 10 mA
Minimum current (Imin) 50 mA
Transition current (Itr) 250 mA
Reference current (Iref) 5 A
Permanent overload (Imax) 6 A
Short-term over-current 120 A for 0.5 s (EN50470-3 and IEC 62053-21)
VOLTAGE (TRMS)
Direct measurement 230VAC Phase/Neutral 400VAC Phase/Phase ±15%
Permanent overload 230 / 400VAC +15%
POWERS
Active Yes
Reactive No*
Resolution 0.1kW
ENERGY
Active Yes
Reactive Yes
Total and partial metering Yes (0 to 9999999kWh)
Bidirectional metering (EA+ and EA-) Yes
Resolution 1kWh
ACCURACY
Active energy Class 1 (IEC 62053-21)
TARIFFS
Tariff management Yes*
Number of tariffs managed 4*
Tariff exchange input No*
METROLOGICAL LED
Impulse weight 10000 impulses / kWh
Colour Red
DISPLAY
Type 7 Digit LED with blue back-lighting
Refresh time 1s
Back-lighting illumination time 30s
List of functions displayed Cf. table below
* Functions available only via communication, the complete list of these functions is given in the down-
loadable M-BUS communication table.
EN
45
COUNTIS E45
