MODBUS RTU / MODBUS TCP for Modulys GP 2.0 - ITYS PRO UPS - Masterys GP4 UPS - Masterys BC+ UPS range - Ref.: IOMXXXOPXX00-EN 00
7.2 UPS reference table, starting from 0x0010
Address Acronym Description
Value
Comments
Length Number of ASCII char.
0x0010 I000 SERIAL NUMBER 10 20
MSB = first char of
string
0x001A I001 SOCOMEC REFERENCE 10 20
MSB = first char of
string
0x0024 I002
USER DEVICE
REFERENCE
612
MSB = first char of
string
0x002A I003
USER DEVICE
LOCATION
612
MSB = first char of
string
7.3 UPS status table, starting from 0x0030
ITYS PRO STATUS
Generic ad-
dress
Bits Acronym Description
0x0030
b00 S000 Load protected by Inverter
OUTPUT STATUS
b01 S001
b02 S002 Load supplied by automatic Bypass
b03 S003
b04 S004 Load OFF
b05 S005
b06 S006 In eco mode
FUNCTIONING MODE
b07 S007
b08 S008
b09 S009 Service Mode
b10 S010
b11 S011 Operating
DEVICE STATUS
b12 S012 Available
b13 S013 On Standby
b14 S014
b15 S015 Maintenance Alert
0x0031
b00 S016 Output Breaker closed
DEVICE ENVIRONMENT
b01 S017
b02 S018
b03 S019
b04 S020
b05 S021
b06 S022
b07 S023 Gen set ON
b08 S024
b09 S025
b10 S026 Automatic Start in progress
PROCEDURES
b11 S027
b12 S028 UPS OFF procedure in progress
b13 S029
b14 S030
b15 S031 Alarm Ack. request
