socomec NETYS PL - 9 Technical Specifications

13
NETYS PL - Ref.: IOMNETPLXX01-GB 02
ENGLISH
9. TECHNICAL SPECIFICATIONS
Models
Power (UPS protection) 600 (360 W) 800 VA (480 W)
Power (Surge protection) 1200 VA 1200 VA
Technology High Frequency Step Wave
Electrical specifications - Input
Voltage 180÷270 V
Frequency (nominal) 50/60 Hz with automatic selection
Mains connection Cable with plug
Electrical specifications - Output
Voltage (in Battery Mode) 230 V ±10%
Frequency (in Battery Mode) 50/60 Hz ±1 Hz
Wave form Stepwave
Protection Overload, deep discharge and short circuit
Load connection sockets
n° 4 load connection socket for UPS and surge protection
n° 2 load connection socket for surge protection
Battery
Typical back-up time (PC + 17” LCD monitor) 15 min 20 min
Battery recharge Under permanent charge even when the UPS is off (mains present)
Reporting and Communication
Communication interface
USB
Local communication software UPS Management software
Environment
Noise level at 1 meter < 40 dBA
Temperature 0÷40 °C (15÷25 °C for optimum battery life)
Environment Humidity: 90% non-condensing
Reference standards EN 62040-1 (safety), EN 62040-2 (EMC)
Mechanical characteristics
Dimensions (W x D x H) 220 x 220 x 123 mm
Net weight 3.6 kg 4.1 kg
