Sofar solar 2200TL-G3 User Manual

SOFAR 1.1K~3.3KTL-G3 User manual
Copyright © Shenzhen SOFARSOLAR Co., Ltd
- 32 -
Removing the AC connector Hold the button to unlock and rotate the knob
counterclockwise to the unlock position, then pull out the AC connector.
Figure 4-23
Make sure the grid is disconnected before removing the AC
connector.
Caution
4.5. RS485,CT,inverter logic interface connection
The communication interface location of the SOFAR1.1K~3.3KTL-G3 is
shown in the figure below.
Figure 4-24
Hold the button
to unlock

Sofar solar 2200TL-G3 Specifications

General

Model	2200TL-G3
Rated Output Power	2200 W
Start Voltage	150V
Number of MPP Trackers	1
Max. Input Current per MPPT	12A
Max. AC Power	2200 W
Max. AC Current	10 A
Rated AC Voltage	230 V
AC Voltage Range	180 V - 280 V
Rated Frequency	50 Hz / 60 Hz
THDi	<3%
Power Factor	>0.99 (at rated power)
DC Switch	Yes
Protection Degree	IP65
Cooling	Natural Convection
Max. Input Current	12A
Type	Grid-Tied Inverter
Operating Temperature Range	-25°C to +60°C
