5. Commissioning of inverter
5.1. Safety inspection before commissioning
Ensure that DC and AC voltages are within the acceptable range
of the inverter.
Attention
5.2. Start inverter
Step 1: Turn ON the DC switch.(optional)
Step 2: Turn ON the AC circuit breaker.
When the DC power generated by the solar array is adequate, the SOFAR
1.1K~3.3KTL-G3inverter will start automatically. Screen showing “normal”
indicates correct operation.
NOTE: Choose the correct country code. (refer to section 6.3 of this manual)
Notice: Different distribution network operators in different countries have different
requirements regarding grid connections of PV grid connected inverters.
Therefore, it's very important to make sure that you have selected the correct
country code according to requirements of local authority.Please consult qualified
electrical engineer or personnel from electrical safety authorities about this.
Shenzhen SOFARSOLAR Co., Ltd. is not responsible for any consequences
arising out of incorrect country code selection.
If the inverter indicates any fault, please refer to Section 7.1 of this manual —
— trouble shooting for help.
NOTE:The inverter can monitor the power grid in real time,The protection can
be realized when the power grid is abnormal, so that the inverter is separated from
the power grid.

Sofar solar 2200TL-G3 Specifications

General

Model	2200TL-G3
Rated Output Power	2200 W
Start Voltage	150V
Number of MPP Trackers	1
Max. Input Current per MPPT	12A
Max. AC Power	2200 W
Max. AC Current	10 A
Rated AC Voltage	230 V
AC Voltage Range	180 V - 280 V
Rated Frequency	50 Hz / 60 Hz
THDi	<3%
Power Factor	>0.99 (at rated power)
DC Switch	Yes
Protection Degree	IP65
Cooling	Natural Convection
Max. Input Current	12A
Type	Grid-Tied Inverter
Operating Temperature Range	-25°C to +60°C
