SOFAR 1.1K~3KTL User manual
Copyright © Shenzhen SOFARSOLAR Co., Ltd
- 47 -
4.5 RS485, CT, inverter logic interface connection for details.
19. MPPT Scan
Shadow scanning, when the component is blocked or abnormal, causing
multiple power peaks, by enabling this function, the peak point of maximum power
can be tracked.
20. Logic interface
Enable or disable logical interfaces. Please refer to this manual 4.5 RS485, CT,
inverter logic interface connection for details.
21. Set Power Ratio (The country is set at 10)
Set generation ratio.
(B) “Event List” Interface as below:
Event List is used to display the real-time event records, including the total
number of events and each specific ID No. and happening time. User can enter
Event List interface through main interface to check details of real-time event
records, Event will be listed by the happening time, and recent events will be listed
in the front. Please refer to below picture. Press “Back” and “Down” to turn the
page in standard interface, then enter into “2.Event List” interface.
2. Event List
1. Current event
2. History event
Fault information
01 ID04 06150825
( Display the event sequence number, event ID
number, and event occurrence time )
(C) “SystemInfo” Interface as below
3.SystemInfo
------Press “OK”
1.Inverter Type
7.Power Factor
2.Serial Number
8.Reflux Power
3.Soft Version
9.Safety Paras
4.Hard Version
10.MPPT Scan
5.Country
11.Power Ratio
6.Relay Command
