The above mentioned parameters are based on tests according to international flashlight testing
standards (ANSI/NEMA FL1) using one 700mAh 16340 Li-ion battery in our laboratory. Results may vary
with different battery or under different environmental conditions. Operation temperature is 0°C -
40°C.
Specifications
Emitter: 1x LH351D with a lifespan of 50,000 hours
Operating voltage: 2.7V – 4.2V
Driver: buck driver
Battery options: 1x 16340 rechargeable lithium-ion battery
Dimension: 73mm (length) × 22.5mm (head diameter)
Weight: 36 grams (without battery)
Flashlight body: Aerospace grade 6061 grade aluminum alloy, CNC manufactured to hard-anodized
to military grade specification type III, anti-abrasive finish to get solid built body, anti-crash
geometry and better heat exchange.
Toughened mineral glass lens
Mode Memory: memorizes the last brightness level used
Reverse polarity protection from improper battery installation
Low voltage warning: When the battery voltage is too low, the LED indicator in the side switch will
start to flash rapidly. Please recharge the battery.
Low voltage protection: The flashlight steps down automatically when the voltage is lower than 3.0V.
It also turns off automatically if the voltage gets too low. Please recharge the battery.
Advanced Temperature Regulation (ATR) technology: As the temperature rises, SC21 Pro is
programmed to automatically step down and step up the brightness to prevent over-heating.
Battery Specifications
Rechargeable li-ion battery
Getting started
Before using the flashlight, unscrew the head from the tube, remove the 16340 battery (if supplied) and
remove the insulating plates on the battery’s poles. Reinsert the battery with the anode side (+) towards
the head, then screw the head back onto the tube. Make sure to fully charge the 16340 battery before
first use.
