5
Installation and Operation
PSX-150
PSX-250
PSX-75
Earth GND
Battery DETECT
Voltage SELECT
230VAC jumper
Figure 3 - Configuring the Internal PSX Power Supplies in a Rackmount System
Figure 4 - PSX 230VAC jumper location
AC Input
cut jumper
for 230VAC
cut jumper
for 230VAC
AC ON
AC Input
AC ON
PSX-150, 250
PSX-75
