Overview
2
Specifications
The following specifications apply to the RM2L-NH Keypad Arming Station:
Data Cable: Recommended data cable is Belden #9841or equivalent. The maximum
length is 4000 feet (1212 meters) between the apC/iSTAR and the RM2L-NH
device.
Power Wiring: Recommended power wiring is Belden #8461 (18 AWG) or #8442
(22 AWG) twisted pair. Maximum length depends on the wire gauge. RM2L-NH
devices can be powered from a local power supply.
Temperature
Indoor: 32° F to 120° F (0° C to 49° C)
Outdoor: -31° F to 151 ° F (-35 ° C to 66° C)
RM 2L-NH Keypad
Arming Station
Table 1 shows the power requirements for RM2L-NH devices
NOTE
The power source can be from a power limited output on an apC or iSTAR.
The local power supply must be a UL Listed Access Control (or Burglar Alarm),
power-limited, Class 2, power source.
TABLE 1. RM2L-NH Power Supply Requirements
RM2L-NH Device Model #
Power Requirements:
12 VDC
With Keypad and LCD RM2L-NH 235 mA nominal
300 mA Peak
