16
MODEL SWH-4000 TECHNICAL
SPECIFICATIONS
Cable Recommendations: 5 core (minimum), shielded, 22 AWG
(minimum) cable.
Connectors: 10 position, 3.5 mm Screw Terminals -
Plug-In
Certifications: FCC Part 15, CE, UL 294
Open Standards
Compliance:
ISO 14443A
ISO 14443B (Depending on specific
implementation)
ISO 15693 (including some partially
compliant credentials)
Other Standards
Compliance:
Deister SmartFrame® in both 125 KHz
and 13.56 MHz implementations
HID® Prox at 125 KHz (All Formats)
Standard Color: Black (other colors available; contact your
Software House® representative)
Dimensions
(height/width/depth):
4.92" × 1.77" × 0.98"
(120 × 45 × 25 mm)
Power Supply Rated Voltage: 9.4 to 16 VDC
110 mA maximum current
