Position and Audio Control Module User Guide
3 Module Interface
The PAC is a single module card installed in a PAC housing suitable for locating at operator
positions. This section explains the front and rear panel connectors, switches, and indicators.
Figure 1: Front Panel
Figure 2: Rear Panel
5
