Solacom PAC - Table 9: Cable X Pin Assignments

Installation
Pin (P1) Signal Pin (P2) Pin (P3) Pin (P4) Pin (P5)
1 Chassis GND 1 1 1 1
2 Tel Mic + 2
3 Tel Hdset + 3
4 Radio Hdset + 2
5 Radio Mic + 3
6 Unassigned
7 Recorder Audio + 2
8 Recorder Active CM 3
9 Radio Bypass CM 4
10 GND 10
11 Radio PTT CM 5
12 Radio Sense 8
13 Footswitch 13
14 Tel Mic - 6
15 Tel Hdset - 7
16 Radio Hdset - 14
17 Radio Mic - 15
18 Unassigned
19 Recorder Audio - 6
20 Recorder Active NO 7
21 Radio Bypass NO 16
22 Unassigned
23 Radio PTT NO 17
24 Radio Sense NO
20
25 Unassigned
Table 9: Cable X Pin Assignments
12
